Water Cooling Conveyor Belt Vulcanizing Equipment Rubber Vulcanizing Machine CE

Water Cooling Conveyor Belt Vulcanizing Equipment Rubber Vulcanizing Machine CE
Water Cooling Conveyor Belt Vulcanizing Equipment Rubber Vulcanizing Machine CE Water Cooling Conveyor Belt Vulcanizing Equipment Rubber Vulcanizing Machine CE Water Cooling Conveyor Belt Vulcanizing Equipment Rubber Vulcanizing Machine CE Water Cooling Conveyor Belt Vulcanizing Equipment Rubber Vulcanizing Machine CE

Large Image :  Water Cooling Conveyor Belt Vulcanizing Equipment Rubber Vulcanizing Machine CE

Product Details:
Place of Origin: China
Brand Name: RUNNING
Certification: CE,SGS
Model Number: ZLJ
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: FCL/LCL
Delivery Time: 5--15days
Payment Terms: T/T, L/C, Western Union, MoneyGram
Supply Ability: 50000sets/year

Water Cooling Conveyor Belt Vulcanizing Equipment Rubber Vulcanizing Machine CE

Description
Application: Conveyor Belt Hot Vulcanizing Joint HS Code: 84778000
Material: Aluminum Alloy Key Selling Points: Long Service Life
Cooling Type: Water Cooling Cooling Time: In 15-30 Mins
Heating Type: Electrical Warranty: 24 Months
High Light:

Water Cooling Conveyor Belt Vulcanizing Equipment

,

CE Conveyor Belt Vulcanizing Equipment

,

Conveyor Belt Rubber Vulcanizing Machine

Water Cooling Conveyor Belt Jointing Machine , Rubber Vulcanizing Machine



Application



Portable type conveyor belt joint vulcanizing press is mainly applied to industries for splicing and repairing conveyor belts such as metallurgy, mine, power plant, port, dock, construction material cement, chemical industry, tobacco, and food automatic line field.



Water Cooling Conveyor Belt Vulcanizing Equipment Rubber Vulcanizing Machine CE 0





Specification of conveyor belt jointing machine



1.  Voltage: 220V 380V 415V 525V 660V 1140V 50HZ 60HZ(Customize available according to your requirement)
2.  Quick water cooling device: 15 minutes From 145 ºCdown to 80 ºCor even lower
3. Cooling source: Water or Air
4. Heating source: Electricity
5. Heating time: from room temperature to vulcanization temperature need less than 20 minutes
6. Heating plate surface temperature difference: ± 1 ºC
7. The temperature adjustment range: 0 ~ 200 ºC(custom)
8. Vulcanization pressure: Max 2.5MPa.
9. Curing temperature: 0 ~ 99min (according to the thickness of the belt to adjust), Usually 10mm~25mins, 20mm~35mins

10. Automatic mute pressure pump
11. Automatic control panel: insulating and waterproof, security alarm, Auto power-off when reach the vulcanization temperature.
   Upgrading explosion proof control box option available.

Water Cooling Conveyor Belt Vulcanizing Equipment Rubber Vulcanizing Machine CE 1

Technical Parameters



Model Applied Width(mm) Motor power Dimension(LxWxH)(mm) Weight(KG)
ZLJ-800x830 800 11.2 1280x830x630 650
ZLJ-1000x830 1000 14.1 1480x830x630 700
ZLJ-1200x830 1200 16.5 1680x830x710 900
ZLJ-1400x830 1400 18.6 1930x830x760 1100
ZLJ-1600x830 1600 21.1 2140x830x800 1320
ZLJ-1800x830 1800 23.3 2300x830x850 1480
ZLJ-2000x830 2000 25.6 2600x830x950 1860



Except the above models, we can design & make joint vulcanizer machine as your requirement, non-standard machines can be customized.


Our Advantages

AUTOMATIC CONTROL BOX

With automatic temperature control, security alarm and automatically switch off the power. The control box can monitor the temperature of 3-5 different points on each heating platen at the same time to ensure the result of jointing.



Water Cooling Conveyor Belt Vulcanizing Equipment Rubber Vulcanizing Machine CE 2



PRESSURE SYSTEM

Signature RUNNING "Pressure Bag" uniform pressure system is lighter up to 4 times than the outdated pressure bag.

The pressure bag can reach full expansion in one time and ensure the uniform pressure up to 3.0MPa.





Water Cooling Conveyor Belt Vulcanizing Equipment Rubber Vulcanizing Machine CE 3



HEATING PLATEN

Custom extruded plank, silicone heating elements (up to 180°C/356°F), and durable composite insulating packaging are used to construct a flexible platen that contours to belt irregularities.
It takes 15~25mins rise up to vulcanizing temperature (about 145°C).
The flush "quick connect" make smooth profile. Recessed power connections are sealed for moisture resistance.





Water Cooling Conveyor Belt Vulcanizing Equipment Rubber Vulcanizing Machine CE 4



COOLING SYSTEM (Option Available)
Custom "Extruded Plank" cooling system within platens is made by several cuprum pipelines, it only takes about 20mins to drop the temperature down to 60°C.



Water Cooling Conveyor Belt Vulcanizing Equipment Rubber Vulcanizing Machine CE 5



PRESSURE PUMP
Automatic mute pressure pump own the features as smaller size, lighter weight and high impact-resistance. Compared with the manual pump, the operating pressure can be 23kg/cm2 (2.3MPa).

Antai Heavy Duty Conveyor Belt Vulcanizing Joint Machine with Water Pressure System

EMBEDDED CONNECTOR

Upgrading to embedded water-cooled connector can effectively prevent damage caused by collision and prolong service life.

Water Cooling Conveyor Belt Vulcanizing Equipment Rubber Vulcanizing Machine CE 7





On Site Splicing Hot Vulcanizing for conveyor belt

The normal package is wooden box(Size: L*W*H). If export to european countries,the wooden box will be fumigated.If container is too tiger,we will use pe film for packing or pack it according to customers special request.



Our Services

Pre-Sales Service

* Inquiry and consulting support.

* Sample testing support.

* View our Factory.

After-Sales Service

* Training how to instal the machine, training how to use the machine.

* Engineers available to service machinery overseas.

Water Cooling Conveyor Belt Vulcanizing Equipment Rubber Vulcanizing Machine CE 9

Water Cooling Conveyor Belt Vulcanizing Equipment Rubber Vulcanizing Machine CE 10
