Broken Hole Hot Vulcanizing Conveyor Belt Repairing Machine 380V Equipment

Broken Hole Hot Vulcanizing Conveyor Belt Repairing Machine 380V Equipment
Broken Hole Hot Vulcanizing Conveyor Belt Repairing Machine 380V Equipment Broken Hole Hot Vulcanizing Conveyor Belt Repairing Machine 380V Equipment Broken Hole Hot Vulcanizing Conveyor Belt Repairing Machine 380V Equipment Broken Hole Hot Vulcanizing Conveyor Belt Repairing Machine 380V Equipment

Large Image :  Broken Hole Hot Vulcanizing Conveyor Belt Repairing Machine 380V Equipment

Product Details:
Place of Origin: QINGDAO, CHINA
Brand Name: RUNNING
Certification: CE
Model Number: YXL-350*350
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: $3000~$4000 / set
Packaging Details: Plywood case (Fumigation-free)
Delivery Time: In stock
Payment Terms: T/T, L/C
Supply Ability: 50sets/month

Broken Hole Hot Vulcanizing Conveyor Belt Repairing Machine 380V Equipment

Description
Usage: Conveyor Belt Repairing Heating Plate Size: 350*350mm
Beam Span: 1100mm Pressurizing Method: Manual Hydraulic Pump
Heating Method: Electricity Voltage: 380V 400V 480V 660V Etc.
High Light:

Hot Vulcanizing Conveyor Belt Repairing Machine

,

Broken Hole Conveyor Belt Repairing Machine

,

380V conveyor belt vulcanizing equipment

Conveyor Belt Broken Hole Hot Vulcanizing Repairing Machine with 350 * 350mm Platen



Usage:



This machine is used for repairing broken holes on the rubber conveyor belt. Its heating plate size is 350*350mm which can repair max. 300*300mm broken holes. And the frame span is 1100mm, so it can be used on repairing 2000mm width rubber conveyor belt.



Broken Hole Hot Vulcanizing Conveyor Belt Repairing Machine 380V Equipment 0



Broken Hole Hot Vulcanizing Conveyor Belt Repairing Machine 380V Equipment 1



Specifications of Conveyor belt repairing machine:



Model Temp. Power Dimensions(L*W*H) Weight pressure
YXL-200x200



145 ºC





1.1kw 1300*200*780mm 145kg ≤2.0Mpa
YXL-250x250 1.4 kw 1300*250*780 mm 149 kg
YXL-300x300 1.6 kw 1300*300*780 mm 152 kg
YXL-350x350 1.9 kw 1300*350*780 mm 163 kg



Conveyor belt repairing process:



1. Transfer machine to the repair site.
2. Fill glue in the damaged areas that need to be repaired (see the adhesive part in the vulcanization process of the belt joints, or the demonstration by our staff when the equipment is being tested).
3. Place the frame under the belt and align it with the damaged area.
4. Place the down heating plate just below the damaged area of the belt and then place the upper frame.
5. Press the hydraulic lever until it reaches enough pressure level.
6. Get the first power wire well connected to the electrical control box. Connect the second wire with the electric control box and the upper and down plates.
Note that it corresponds to the sign on the electric control box.
7. Turn on the electric control box and start the vulcanizing repair process.



Shipping package of Conveyor belt repairing machine:



Broken Hole Hot Vulcanizing Conveyor Belt Repairing Machine 380V Equipment 2
