Lightweight Hot Splicing Rubber Conveyor Belt Repairing Machine For Edge Repair

Lightweight Hot Splicing Rubber Conveyor Belt Repairing Machine For Edge Repair
Lightweight Hot Splicing Rubber Conveyor Belt Repairing Machine For Edge Repair
Lightweight Hot Splicing Rubber Conveyor Belt Repairing Machine For Edge Repair Lightweight Hot Splicing Rubber Conveyor Belt Repairing Machine For Edge Repair Lightweight Hot Splicing Rubber Conveyor Belt Repairing Machine For Edge Repair Lightweight Hot Splicing Rubber Conveyor Belt Repairing Machine For Edge Repair Lightweight Hot Splicing Rubber Conveyor Belt Repairing Machine For Edge Repair

Large Image :  Lightweight Hot Splicing Rubber Conveyor Belt Repairing Machine For Edge Repair

Product Details:
Place of Origin: China
Brand Name: RUNNING
Certification: CE,SGS
Model Number: XL
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: FCL/LCL
Delivery Time: 5--15days
Payment Terms: T/T, L/C, Western Union, MoneyGram
Supply Ability: 50000sets/year

Lightweight Hot Splicing Rubber Conveyor Belt Repairing Machine For Edge Repair

Description
Condition: New Application: Conveyor Belt Edge Repair
Material: High Strength Aluminum Alloy Transport Package: Wooden Box
Working Pressure: 0~2MPa Belt Vulcanizing Temperature: 145ºC
Heating Time: Less Than 25 Minutes Curing Time Set Adjustable Range: 0-99 Minutes
After-Sales Service System: Video Technical Support Warranty: 24 Months
High Light:

Lightweight Conveyor Belt Repairing Machine

,

Rubber Conveyor Belt Repairing Machine

,

Lightweight Rubber Belt Repair Machine

Light Weight Hot Splicing Rubber Belt Edge Repair Vulcanizing Machine



Product Introduction



XL strip vulcanizing repair machine ,also known as the belt-edge repair vulcanizing machine, is mainly applied to repair the long-distance damage ,longitudinal piercing as well as edge damages on the conveyor belt on site. It's time-saving, efficient and easy operated.

Lightweight Hot Splicing Rubber Conveyor Belt Repairing Machine For Edge Repair 0





Technical Parameters (Reference)





Lightweight Hot Splicing Rubber Conveyor Belt Repairing Machine For Edge Repair 1



Special requirements: Voltage, Pressure, Temperature, Heating platen dimension etc. we can make special for you, if you have any requirements.



 Advantages



The frame is made of high-strength aluminum alloy, it's small size, portable,safe and reliable.



Features



1.Rapid heating: from 20 ℃ to 145 ℃ only takes 20-25 minutes;
2.Uniform temperature: heating plate maximum temperature and minimum temperature difference does not exceed 3 ℃;
3. Rapid cooling: the heating plate from 145 ℃ to 65℃ cooling only takes 15-20 minutes;
4.Durable High-strength durable aluminum alloy allows maximum pressure 2.0 Mpa





Lightweight Hot Splicing Rubber Conveyor Belt Repairing Machine For Edge Repair 2

Lightweight Hot Splicing Rubber Conveyor Belt Repairing Machine For Edge Repair 3



Application method


1.Fill glue inthe damaged areas that need to be repaired(see the adhesive part in the vulcanization process of the belt joints, or the demonstration by our staff when the equipment is being tested);
2.Put the bottom plate, water pressure plate and lower heating plate under the damaged areasof the belt according to the structural diagram.
3.Put the upper heating plate,Insulation board on the damaged areasof the belt.Align the top and bottom plates.
4. Lockedequidistantlythen tighten the bolts.
5.Get the first power wire well connected to electric control box. Connect the second wire with electric control box and the upper and down plates.Note that it corresponds to the signon the electric control box.
6.Connect the end of the high pressure pipe with inlet opening of water pressure plate. And connect another end of the high-pressure pipe with water output hole of water pump.Switch on, add pressure upon vulcanizing machine.





Lightweight Hot Splicing Rubber Conveyor Belt Repairing Machine For Edge Repair 4

On Site Splicing Hot Vulcanizing for conveyor belt

The normal package is wooden box(Size: L*W*H). If export to european countries,the wooden box will be fumigated.If container is too tiger,we will use pe film for packing or pack it according to customers special request.



Our Services

Pre-Sales Service

* Inquiry and consulting support.

* Sample testing support.

* View our Factory.

After-Sales Service

* Training how to instal the machine, training how to use the machine.

* Engineers available to service machinery overseas.



FAQ

1. Q: Are you a manufacturer or trading company?
A: We are the manufacturer. We have our own plant, workers and technology research development department.
2 .Q: Where is your factory located? How can I visit there?
A: Our factory address is located in beautiful Qingdao, West Coast Economic Zone. The nearest airport is Qingdao Liuting International Airport. Kindly send flight information in advance, so that we can pick you up at the airport, and book hotels as you require.
3. Q: What are your hot sale machines?
A: The main products are conveyor belt vulcanizing joint machine, mine explosion-proof conveyor belt vulcanizing machine, conveyor belt repair machine, conveyor belt peeling machine and other relevant equipment.
4. Q: How does your factory do regarding quality control?
A: Quality is priority No. 1 and we have our own quality control department. We will make a strict inspectin before the machines leave our factory.
5 .Q: Are the technical parameter is fixed?
A: Basically, each model corresponding to the related machine. But we can design different type machines according to the client's requirement.


Customer Vistiting



Lightweight Hot Splicing Rubber Conveyor Belt Repairing Machine For Edge Repair 6

Lightweight Hot Splicing Rubber Conveyor Belt Repairing Machine For Edge Repair 7

Lightweight Hot Splicing Rubber Conveyor Belt Repairing Machine For Edge Repair 8

Lightweight Hot Splicing Rubber Conveyor Belt Repairing Machine For Edge Repair 9


























Technical Parameters (Reference)
