Water Cooling Rubber Conveyor Belt Vulcanizer Nylon Belt Jointing Machine 50/60HZ

Water Cooling Rubber Conveyor Belt Vulcanizer Nylon Belt Jointing Machine 50/60HZ
Water Cooling Rubber Conveyor Belt Vulcanizer Nylon Belt Jointing Machine 50/60HZ
Water Cooling Rubber Conveyor Belt Vulcanizer Nylon Belt Jointing Machine 50/60HZ Water Cooling Rubber Conveyor Belt Vulcanizer Nylon Belt Jointing Machine 50/60HZ Water Cooling Rubber Conveyor Belt Vulcanizer Nylon Belt Jointing Machine 50/60HZ Water Cooling Rubber Conveyor Belt Vulcanizer Nylon Belt Jointing Machine 50/60HZ Water Cooling Rubber Conveyor Belt Vulcanizer Nylon Belt Jointing Machine 50/60HZ

Large Image :  Water Cooling Rubber Conveyor Belt Vulcanizer Nylon Belt Jointing Machine 50/60HZ

Product Details:
Place of Origin: China
Brand Name: RUNNING
Certification: CE,SGS
Model Number: ZLJ
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: FCL/LCL
Delivery Time: 5--15days
Payment Terms: T/T, L/C, Western Union, MoneyGram
Supply Ability: 50000sets/year

Water Cooling Rubber Conveyor Belt Vulcanizer Nylon Belt Jointing Machine 50/60HZ

Description
Condition: New Application: Conveyor Belt Hot Vulcanizing Joint
Material: Aluminum Alloy Color: Silver
System: Water System Cooling Time: In 15-30 Mins
Heating: Electrical Warranty: 24 Months
High Light:

Rubber Conveyor Belt Vulcanizer

,

60HZ Conveyor Belt Vulcanizer

,

50hz nylon belt jointing machine

Electric Heating Water Cooling Rubber Conveyor Belt Vulcanizer



Product Introduction



Conveyor tape vulcanized joint (repair) machine series of products using modular, electric heating, hot plate temperature difference is small, the new pressure water bag pressure uniform, lightweight, reliable quality, the use of new digital control box, long life, good performance, light weight. Applicable to canvas, nylon, steel cord,PVG and other tape vulcanized joints (repair).Water-cooled connector (repair) curing machine, in order to save the curing time of vulcanization, and improved a new type of tape curing machine, the device as long as the use of the site with ordinary water, you can complete the curing, the hot plate water cooling, From the curing temperature to 60 ℃ only 20 minutes, is a new, ideal conveyor belt cement (repair) equipment.



Water Cooling Rubber Conveyor Belt Vulcanizer Nylon Belt Jointing Machine 50/60HZ 0





Main Parts & Fittings



ZLJ conveyor belt vulcanizing machines can be used by one or multiple combinations according to the joint length of the belt.The main configuration of a single vulcanizing machine is as following:

Name

Amout

The whole machine

1 set

Stab a wrench

2 piece

Clip tight device

1 set

Electricity controls box

1 set

A cable

1 root

Two cable

2 root

Hot electric resistance

2 root

SD hand press pump (from choose)

1 set

Pressure pipe

2 root

Cold water system(can choose)

1 set



Water Cooling Rubber Conveyor Belt Vulcanizer Nylon Belt Jointing Machine 50/60HZ 1

Water Cooling Rubber Conveyor Belt Vulcanizer Nylon Belt Jointing Machine 50/60HZ 2



Our Advantages



AUTOMATIC CONTROL BOX

With automatic temperature control, security alarm and automatically switch off the power. The control box can monitor the temperature of 3-5 different points on each heating platen at the same time to ensure the result of jointing.



Water Cooling Rubber Conveyor Belt Vulcanizer Nylon Belt Jointing Machine 50/60HZ 3



PRESSURE SYSTEM

Signature RUNNING "Pressure Bag" uniform pressure system is lighter up to 4 times than the outdated pressure bag.

The pressure bag can reach full expansion in one time and ensure the uniform pressure up to 3.0MPa.





Water Cooling Rubber Conveyor Belt Vulcanizer Nylon Belt Jointing Machine 50/60HZ 4



HEATING PLATEN

Custom extruded plank, silicone heating elements (up to 180°C/356°F), and durable composite insulating packaging are used to construct a flexible platen that contours to belt irregularities.
It takes 15~25mins rise up to vulcanizing temperature (about 145°C).
The flush "quick connect" make smooth profile. Recessed power connections are sealed for moisture resistance.



Water Cooling Rubber Conveyor Belt Vulcanizer Nylon Belt Jointing Machine 50/60HZ 5



COOLING SYSTEM (Option Available)
Custom "Extruded Plank" cooling system within platens is made by several cuprum pipelines, it only takes about 20mins to drop the temperature down to 60°C.



Water Cooling Rubber Conveyor Belt Vulcanizer Nylon Belt Jointing Machine 50/60HZ 6



PRESSURE PUMP
Automatic mute pressure pump own the features as smaller size, lighter weight and high impact-resistance. Compared with the manual pump, the operating pressure can be 23kg/cm2 (2.3MPa).

Antai Heavy Duty Conveyor Belt Vulcanizing Joint Machine with Water Pressure System



Product Application

1. Steel Cord Belt Intermediate Rubber is an uncured rubber for hot vulcanized belt splicing.

2. It is designed to use as an inter-core cord rubber replacement material in splicing steel cord conveyor belts or a tie gum in fabric belts.
3. The material is designed to bond to cured intercore rubber and wire cords in all standard grade steel cord conveyor belts, as well as fabric belt cured skim rubber and general bond improvement material for general grade fabric conveyor belts.
The ZLJ sectional has uniform pressure bag and aluminum/steel bolt and high grade aluminum platens and beams with restraining system set as standard. Such belt splicing system designed to be portable and easy to set-up and remove from the site.
We can manufacture to all sizes and pressure up to 200 psi required for different fabric belts and steelcord belts.



Water Cooling Rubber Conveyor Belt Vulcanizer Nylon Belt Jointing Machine 50/60HZ 8





Technical Parameters (Reference)




Model

Applied Width(mm)

motor power

Dimension(LxWxH)(mm)

Weight(KG)

ZLJ-800x830

800

11.2

1280x830x630

650

ZLJ-1000x830

1000

14.1

1480x830x630

700

ZLJ-1200x830

1200

16.5

1680x830x710

900

ZLJ-1400x830

1400

18.6

1930x830x760

1100

ZLJ-1600x830

1600

21.1

2140x830x800

1320

ZLJ-1800x830

1800

23.3

2300x830x850

1480

ZLJ-2000x830

2000

25.6

2600x830x950

1860





Specification



1. Voltage: 220V 380V 415V 525V 660V 1140V 50HZ 60HZ(Customize available according to your requirement)
2. Quick water cooling device: 15 minutes From 145 ºCdown to 80 ºCor even lower
3. Cooling source: Water or Air
4. Heating source: Electricity
5. Heating time: from room temperature to vulcanization temperature need less than 20 minutes
6. Heating plate surface temperature difference: ± 1 ºC
7. The temperature adjustment range: 0 ~ 200 ºC(custom)
8. Vulcanization pressure: Max 2.5MPa.
9. Curing temperature: 0 ~ 99min (according to the thickness of the belt to adjust)
    Usually 10mm~25mins, 20mm~35mins

10. Automatic mute pressure pump
11. Automatic control panel: insulating and waterproof, security alarm, Auto power-off when reach the vulcanization temperature.
     Upgrading explosion proof control box option available.


Antai Heavy Duty Conveyor Belt Vulcanizing Joint Machine with Water Pressure System

On Site Splicing Hot Vulcanizing for conveyor belt

The normal package is wooden box(Size: L*W*H). If export to european countries,the wooden box will be fumigated.If container is too tiger,we will use pe film for packing or pack it according to customers special request.

Our Services

Pre-Sales Service

* Inquiry and consulting support.

* Sample testing support.

* View our Factory.

After-Sales Service

* Training how to instal the machine, training how to use the machine.

* Engineers available to service machinery overseas.



FAQ

1. Q: Are you a manufacturer or trading company?
A: We are the manufacturer. We have our own plant, workers and technology research development department.
2 .Q: Where is your factory located? How can I visit there?
A: Our factory address is located in beautiful Qingdao, West Coast Economic Zone. The nearest airport is Qingdao Liuting International Airport. Kindly send flight information in advance, so that we can pick you up at the airport, and book hotels as you require.
3. Q: What are your hot sale machines?
A: The main products are conveyor belt vulcanizing joint machine, mine explosion-proof conveyor belt vulcanizing machine, conveyor belt repair machine, conveyor belt peeling machine and other relevant equipment.
4. Q: How does your factory do regarding quality control?
A: Quality is priority No. 1 and we have our own quality control department. We will make a strict inspectin before the machines leave our factory.
5 .Q: Are the technical parameter is fixed?
A: Basically, each model corresponding to the related machine. But we can design different type machines according to the client's requirement.
